• 5 × 10/100/1000 Mbps PoE RJ45 port
• Port 5 (PoE IN): IEEE 802.3af/at/bt compliant
• Ports 1 to 4 (PoE OUT): IEEE 802.3af/at compliant, 60 W total PoE power budget
• 6 kV surge protection for PoE ports
• PoE power management
• Gigabit network access
• Wire-speed forwarding with non-blocking architecture
• Store-and-forward switching
• Rugged high-strength metal housing
• Fanless design with high reliability

General
Shell
Metal material
Net Weight
0.25 kg (0.55 lb)
Gross Weight
0.50 kg (1.10 lb)
Dimensions (W × H × D)
105.00 mm × 27.6 mm × 83.1 mm (4.13'' × 1.08'' × 3.27'')
Operating Temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage Temperature
–40 °C to 85 °C (–40 °F to 185 °F)
Operating Humidity
5% to 95% (no condensation)
Relative Humidity
5% to 95% (no condensation)
Power Supply
IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt Hi-PoE Power Supply
Installation Mode
Desk-Mounted,Wall-Mounted
Surge Protection
6 kV
Network Parameters
Ports
4 × Gigabit PoE port (Output),1 × Gigabit PoE port (Input)
MAC Address Table
2 K
Switching Capacity
10 Gbps
Packet Forwarding Rate
7.44 Mpps
Internal Cache
1 Mbits
PoE Power Supply
PoE Standard
IEEE 802.3af;IEEE 802.3at
PoE Power Pin
8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE Port
PoE Output: Ports 1 to 4 PoE Input: Port 5
Max. Port Power
30 W
PoE Power Budget
60 W
